Echogear EGLF3 - Drill Pilot Holes; Secure Wall Plate with Lag Bolts

11
Drill Holes
2.3 A
7/32 in.
(5.5 mm)
2¾
in. (6.9 cm)
Bit
Secure Wall Plate
2.4 A
06
07
08
4X
Continue
STEP 2.5
on PAGE 14
CAUTION:
DO NOT OVER-TIGHTEN
the lag bolts
07
. Tighten only enough to
securely fasten the wall plate
06
to the wall.
