Echogear EGLF3 - Insert Concrete Anchors; Secure Wall Plate in Concrete

13
Insert Concrete Anchors Secure Wall Plate
2.3 B 2.4 B
4X
06
09
07
08
"whichever way your
mind works"
Continue
STEP 2.5
on PAGE 14
CAUTION:
DO NOT OVER-TIGHTEN
the lag bolts
07
. Tighten only enough to
securely fasten the wall plate
06
to the wall.
FLUSH
