Echogear EGLF3 - Adjustments and Removal; Remove TV from Mount

19
Side-to-Side SHIFT REMOVE YOUR TV
4X
06
IMPORTANT: REMOVE YOUR TV before
adjusting. Only LOOSEN screws
L
to adjust -
DO NOT REMOVE. Securely tighten screws
L
when finished adjusting arm.
s
L
"Don't be
a hero!"
"that's MY move"
HEAVY!
You may need
assistance with
this step.
For Wood Stud ONLY
DO NOT Adjust for concrete installs
