6
M8 x 25mm
M8 x 50mm
M8 x 16mm M8 x 35mm
M6 x 12mm M6 x 35mm
5/16 x 2¾ in.
5/16 in.
1/4-20 x 3/4 in.
M5 x 12mm
M5 x 12mm
Fischer UX10 x 60R Anchor
REMEMBER THE LAST TIME
YOU “WINGED IT”?
STUFF FOR STEP 2
STUFF FOR STEP 3
Wall Plate Template
Wall Plate/Arm
Lag Bolt
Concrete
Anchor
Lag Bolt Washer
Extension
Screw
Extension
Bracket
End Cap
qty.1
05
qty.1
06
qty.4
07
qty.4
10
qty.4
11
qty.4
08
qty.2
13
qty.4
09
qty.4
12
L
Lateral Shift Screws
(qty. 4)
(attached)
Cable Management
Clip
