13
Drill Holes
2.4 A
1/8 in.
(3 mm)
2¾
in. (6.9 cm)
Bit
Secure Wall Plate
2.5 A
11
12
CAUTION: Avoid potential personal injury or
property damage! All four lag screws
11
MUST BE
firmly tightened to prevent unwanted
movement of the wall plate assembly.
4X
7,8,9,10
Continue
STEP 3
on PAGE 18
