15
Insert Concrete Anchors Secure Wall Plate
2.4 B 2.5 B
4X
13
11
12
CAUTION: Avoid potential personal injury or
property damage! All four lag screws
11
MUST BE
firmly tightened to prevent unwanted
movement of the wall plate assembly.
Continue
STEP 3
on PAGE 18
7,8,9,10
"whichever way your
mind works"
FLUSH
