17
CAUTION: Avoid potential personal injury or
property damage! All four lag screws
S2
MUST BE
firmly tightened to prevent unwanted movement of
the wall plate assembly.
a
b
c
d
S2
S1
S3
S1
7,8,9,10
Install Anchors Secure Wall Plate
2.4 C 2.5 C
