Fischer UX10 x 60R Anchor
REMEMBER THE LAST TIME
YOU “WINGED IT”?
1/4 x 2¾ in.
WARNING: DON'T FEED TO CHILDREN
—
This product contains small items that could be a choking
hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are
missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
Never use damaged parts!
What’s in the box ... What's in the booooxx
NOTE: Not all hardware included in this kit will be used.
STUFF FOR STEP 1
TV Screws (qty. 4 each)
[Only one size fits your TV]
Washers Spacers
[If necessary]
TV
Brackets
qty.1
qty.1
qty.4 each
M6
M4
2.5mm
M4
M8/M6
M8
01
02 03
qty.8
qty.4
22mm
05
04
