51-0078-0100 Potenciòmetre etapes.doc 1 of 1
Announcement addressed to Technical Support Services
Involved series:
APA1400 / APA1000 / APA600
PAM1100 / PAM2100
MPA4-80 / MPA6-80 / MPA4-150
VOLUME potentiometer replacement.
Replaced service part code: FCPR210040
When this potentiometer is being replaced, after soldering it on the printed circuit
board, the two leads should be shorted as shown in the picture, in order to ensure a
correct performance depending on the available service part.
author:
J. Colomines
date:
020426
project:
product:
POWER AMPLIFIERS
ECLER
approved:
num:
51.0078
version:
01.00
title:
TECHNICAL BRIEFING
