Ecler APA2000 Service Manual

author: Queralt date: 000913
approved:
num:
40.0049 version: 01.00
D101 LED3G FCLED300VE
D102 LED3G FCLED300VE
D103 LED3R FCLED300RO
D104 LED3Y FCLED300AM
D105 LED3R FCLED300RO
D106 LED3Y FCLED300AM
D107 UNFITTED FCLED300AM
R101 10kAx2 FCPR210040
R102 10kAx2 FCPR210040
W100 7.5mm FCPONT0075
W101 12.5mm FCPONT0125
W102 7.5mm FCPONT0075
W103 7.5mm FCPONT0075
WI101 1005.04.50 FC4I005450
WI102 1007.05.00 FC4K007500
WI103 1004.01.80 FC4G004180
WI104 1004.01.80 FC4G004180
REFERENCE VALUE CODE
PARTS LIST
PRINTED CIRCUIT 11.0775-01.01
model:
EP03-99C&D
E
C
LER
40-0049-0100 EP03-99c&d.xls SHEET 1 OF 1
