ECOFLEX T1203 - Page 9

Attach first set of legs (C,D) to slats (E,F,G) using wood joint connectors (3). Attach second set of legs (C,D) to
slats (E,F,G) using wood joint connectors (3). Insert wood dowels (6) into both sets of legs (E,D).
E
C
C
E
Insert barrel nuts (8) into crossbeams (H,I). Attach crossbeams (H,I) to first set of legs (C,D) using joint
connectors (1). Joint connectors (1) will screw into barrel nuts (8).
I
C
H
C
Insert barrel nuts (8) into crossbeams (H,I). Attach second set of legs (D,C) to crossbeams (H,I) using joint
connectors (1).
I
H
