Water Treatment System Parts List
Key
No.
Part No. Description
– 7112963
Distributor O-Ring Kit
(includes Key Nos. 1-3)
1
á
O-Ring, 73.0 x 82.6 mm
2
á
O-Ring, 20.6 x 27.0 mm
3
á
O-Ring, 69.9 x 76.2 mm
4 7265025 Filter Screen
5 7077870 Top Distributor
6 7105047 Repl. Bottom Distributor
– 7331177
Tank Neck Clamp Kit
(includes Key Nos. 7 & 8)
7
á
Clamp Section (2 req.)
8
á
Retainer Clip (2 req.)
9 7334696 Repl. Resin Tank, 25.4 x 88.9 cm
10
0502272 Resin, 1 cu. ft.
7301619 Activated Carbon
11 7331143 Repl. Brine Tank
12 7334183 Rim
13 7330985 Top Cover (order decal below)
14 7344552 Faceplate Decal
Key
No.
Part No. Description
15 7330993 Salt Lid (order decal below)
¢
7334230 Instruction Decal
16 7331834
Repl. Electronic Control Board
(PWA)
17 7351054 Power Supply, 24V DC
18 7155115 Cover, Brinewell
19 7338145 Brinewell
– 7332204
Brinewell Mounting Hardware Kit
(includes Key Nos. 20-22)
20
á
Wing Nut, 1/4-20
21
á
Spacer, 19.1 mm long
22
á
Screw, 1/4-20 x 15.9 mm
– 7331258
Overflow Hose Adaptor Kit
(includes Key Nos. 23-25)
23
á
Adaptor Elbow
24
á
Grommet
25
á
Hose Clamp
26 7310202 Brine Valve Assembly
27 7327568 Float, Stem & Guide Assembly
28 7139999 Drain Hose
¢
7370008 Owner’s Manual
¢ Not illustrated.
To order repair parts call toll free 1-800-693-1138.
Manufactured and warranted by
Ecodyne Water Systems
1890 Woodlane Drive
Woodbury, MN 55125
Questions? Call Toll Free 1-800-693-1138 or visit www.ecopure.com
When you call, please be prepared to provide the model and serial number,
found on the rating decal, typically located on the rim below the salt lid hinges.
