7
CONTENU DU KIT
KIT CONTENT
PIECES CROCHET DE REMORQUAGE
(A) Crochet de remorquage (crochet+tige un bout fil.+chape M2+4 vis
M3x15mm+4 rondelles ..................................................................................1 set
PIECES TRAIN D’ATTERRISSAGE
(A) Train avant amorti
(avec amortisseur à gaz et axe de roue) ...............................1
(B) Fixation train avant (vis M4x25mm) .................................................................. 4
(C) Tringlerie dirigibilité (avec chapes et silent-bloc “Servo-Saver”) ....................1 set
(D) Train principal..................................................................................................1
(E) Fixation train principal (vis M4x30mm+écrou nylstop M4) ............................. 4 sets
(F) Axe de roue train principal (avec 2 bagues d’arrêt de roue) ....................... 2 sets
PIECES MOTEUR
(A) Fuselage .........................................................................................................1
(B) Capot moteur ..................................................................................................1
(C) Fixation capot moteur (vis à bois 3x14mm) ...................................................7
(D) Réservoir 800cc ........................................................................................1 set
(E) Tringlerie des gaz (avec chapes) ..............................................................1 set
(F) Verrière (ajustée sur son baquet-cabine) .................................................1 set
(G) Fixation cabine (vis M3x15mm+rondelle spéciale anti-desserrage) ..... 2 sets
(H) Fixation verrière (vis à bois 2x8mm) ..............................................................7
REMOTE TOWING HOOK PARTS
(A) Remote towing hook (hook+one side thread. rod+M2 clevis+4 M3x15mm
screws+4 washers ..........................................................................................1 set
LANDING GEAR PARTS
(A) Nose gear
(with gas shock and wheel axis) ........................................................1
(B) Nose gear fixing (M4x25mm screw) ..................................................................4
(C) Steering pushrod (with clevises and “Servo-Saver” device) ...........................1 set
(D) Main gear ........................................................................................................1
(E) Main gear fixing (M4x30mm screw+M4 lock nut) ............................................. 4 sets
(F) Main gear wheel axis (with 2 wheel stoppers) ............................................ 2 sets
ENGINE PARTS
(A) Fuselage .........................................................................................................1
(B) Engine cowl .....................................................................................................1
(C) Engine cowl fixing (self-tapping screw 3x14mm) ............................................7
(D) 800cc gasoline tank ..................................................................................1 set
(E) Throttle pushrod (with clevises) ...............................................................1 set
(F) Canopy (fitted on its frame) ......................................................................1 set
(G) Canopy frame fixing (M3x15mm screw+special washer) .......................2 sets
(H) Canopy fixing (2x8mm self-tapping screw) .....................................................7
WINGS PARTS
(A) Wing
(with aileron and flap installed on their hinge point to be glued) ..................(L/R)
......................................................................................................................1 each
(B) Ailerons and flaps pushrod (M3 threaded rod) ................................................. 4
(C) Ball clevis with screws (M3x15 screw+lock nut+washer) ........................... 4 sets
(D) Ailerons and flaps control horn ..............................................................4 sets
(E) Wing joiner (Ø30mm carbon tube) ...................................................................... 1
(F) Wing screw attachment (plastic M4x16mm) ....................................................... 4
EMPENNAGES PARTS RUDDER
(A) Horizontal empennage ...................................................................................1
(B) Horizontal empennage fixing (screw M4x40mm+washer) ...........................1set
(C) Fin and rudder .................................................................................................2
(D) Fin fixing (screw M3x20mm+washer) ......................................................... 4 sets
(E) Fin reinforcement bar ......................................................................................2
(F) Fin reinforcement bar fixing (screw M3x22mm+nut M3 + 2 screws M3x25mm+2
washers) ......................................................................................................... 2 sets
(G) Rudder servo fixing (1 plastic cover+2 hard wood blocks+4 tapping screws
2,2x12mm) ...................................................................................................... 2 sets
(H) Rudder pushrod (M2 thread. rod one end+M2 clevis+nut) ......................... 2 sets
(I) Rudder control horn .................................................................................2 sets
EMPENNAGES PARTS ELEVATOR
(A) Ø6mm dowel ....................................................................................................2
(B) Stab cover .......................................................................................................1
(C) Elevator pushrod (M3 threaded rod) ................................................................. 1
(D) Ball clevis with screws (M3x15mm screw+lock nut+washer) ...................... 2 sets
(E) Elevator control horn ................................................................................1 set
PIECES AILES
(A) Aile (avec aileron et volet montés sur charnières et à coller) .................(G/D)
.............................................................................................................1 de chaque
(B) Tringlerie ailerons et volets (tige filetée M3) ..................................................4
(C) Chape rotule avec visserie (vis M3x15mm+écrou nylstop+rondelle) ... 4 sets
(D) Guignol ailerons et volets ........................................................................ 4 sets
(E) Clé d’aile (tube carbone Ø30mm) ...................................................................1
(F) Vis fixation d’aile (plastique M4x30mm) .........................................................4
PIECES EMPENNAGES DIRECTION
(A) Empennage horizontal ...................................................................................1
(B) Fixation empennage hor. (vis M4x40mm+rondelle) ................................1set
(C) Dérive ..............................................................................................................2
(D) Fixation dérive (vis M3x20mm+ rondelle) ............................................. 4 sets
(E) Barre de renfort dérive ...................................................................................2
(F) Fixation barre de renfort dérive (vis M3x22mm+écrou M3+2 vis
M3x25mm+2 rondelles) ...............................................................................2 sets
(G) Fixation servo direction (1 carénage plastique+2 blocs bois dur+4 vis à
bois 2,2x12mm) ............................................................................................2 sets
(H) Tringlerie de direction (tige fil. un bout M2+chape M2+écrou) ............2 sets
(I) Guignol direction ....................................................................................... 2 sets
PIECES EMPENNAGES PROFONDEUR
(A) Téton Ø6mm ....................................................................................................2
(B) Carénage de stab ............................................................................................1
(C) Tringlerie profondeur
(tige filetée M3) ............................................................... 1
(D) Chape rotule avec visserie (vis M3x15mm+écrou nylstop+rondelle) .......... 2 sets
(E) Guignol profondeur ....................................................................................1 set
55
