6
Introducing the Motherboard
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
Socket AM3 for AMD Six-Core Phenom
TM
II/ PhenomII
TM
X4/
Phenom
TM
/ Athlon
TM
II/ Sempron
TM
processors
2. CPU_FAN
CPU cooling fan connector
3. DDR3_1~4
240-pin DDR3 SDRAM slots
4. ATX_POWER
Standard 24-pin ATX power connector
5. SYS_FAN
System cooling fan connector
6. CASE
CASE open header
7. SATA1~5
Serial ATA connectors
8. SPK
Speaker header
9. USBPWR_F2
Front panel USB power select jumper
10. F_PANEL
Front panel switch/LED header
11. SPI_DEBUG
SPI debug header-for factory use only
12. CLR_CMOS
Clear CMOS jumper
13. F_USB3
Front Panel USB header
14. USBPWR_F1
Front panel USB power select jumper
15. F_USB1~2
Front Panel USB headers
16. PWR_FAN
Power cooling fan connector
17. COM
Onboard serial port header
18. SPDIFO
SPDIF out header
19. F_AUDIO
Front panel audio header
20. PCI1~2
32-bit add-on card slots
21. PCIE16X_S
PCI Express x16 slot for graphics interface(The second PCIE
16X runs at X4 mode.)
22. PCIE1~2
PCI Express x1 slots
23. PCIEX16
PCI Express x16 slot for graphics interface
24. USBPWR_R1~2
Rear panel USB PS/2 power select jumper
25. ATX12V 8-pin +12V power connector
This concludes Chapter 1. The next chapter explains how to install the motherboard.
