ECS APLD-I User Manual

APLD-I USER MANUAL
4
Table of Motherboard Components
LABEL
COMPONENTS
1. SoC
Intel® Apollo Lake 1296 BGA
2. ATX_PWR
Standard 24-pin ATX power connector* (or
DC_IN port at rear panel)
3. CLR_CMOS
Clear CMOS jumper
4. CASE
Case open header
5. LDC Debug card header
6. DIMM
204-pin DDR3L SDRAM SO-DIMM
7. F_PANEL
Front panel switch/LED header
8. LPT Onboard parallel port header
9. COM1~2 Onboard serial port headers
10. BZ
Buzzer
11. SYS_FAN
4-pin system cooling fan connector
12. SATA_PWR
SATA power connector
13. SATA2
Serial ATA 6Gb/s connector (shares the same
signal with M.2 slot)
14. SATA1
Serial ATA 6Gb/s connector
15. USB3F
Front panel USB 3.0 header
16. SPKR
Amplifier speaker header
17. MONO
MONO jumper
18. F_AUDIO
Front panel audio header
19. M2_2280M
M.2 slot for 2242/2260/2280 SATA SSD (shares
the same signal with SATA2)
20. F_USB1~2
Front panel USB 2.0 headers
21. BT
Battery
Note: * VGA port(real panel I/O) + DC_IN port(real panel I/O) and DP port
(real panel I/O) + ATX_POWER header(internal I/O header) are alternative
options of the motherboard.

ECS APLD-I Specifications

General

Brand	ECS
Model	APLD-I
Category	Motherboard
Language	English
