USB1: Extended USB header
The mainboard has USB ports installed on the rear edge I/O port array. Some
computer cases have a special module that mounts USB ports at the front of
the case. If you have this kind of case, use auxiliary USB connectors USB1 to
connect the front-mounted ports to the mainboard.
Pin Signal Name Pin Signal Name
1
3
5
7
9
VERG_FP_USBPWR0
USB_FP_P0-
USB_FP_P0+
GROUND
KEY
2
4
6
8
10
VERG_FP_USBPWR0
USB_FP_P1-
USB_FP_P1+
GROUND
USB_FP_OC0
WOL1: Wake On LAN
If you have installed a LAN card, use the cable provided with the card to plug
into the mainboard WOL1 connector. This enables the Wake On LAN (WOL1)
feature. When your system is in a power-saving mode, any LAN signal auto-
matically resumes the system. You must enable this item using the Power
Management page of the Setup Utility.
Pin Signal Name
1
2
3
5VSB
Ground
SENSE
IR1: Infrared port
The mainboard supports an Infrared (IR1) data port. Infrared ports allow the
wireless exchange of information between your computer and similarly
equipped devices such as printers, laptops, Personal Digital Assistants
(PDAs), and other computers.
Pin Signal Name Pin Signal Name
1
2
3
NC
Key
+5V
4
5
6
Ground
IRTX
IRRX
18
