Quick Start Guide
– 4 –
DRAFT
Hardware Specifications
AP Chassis
Size (WxDxH) 195 x 195 x 39 mm (7.68 x 7.68 x 1.54 in.)
Weight 0.65 kg (1.435 lb)
Temperature Operating: -20° C to 50° C (-4° F to 122° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
Network Interfaces
Ports Uplink(PoE) RJ-45 Port: 2.5G, PoE PD
LAN1 RJ-45 Port: 1000BASE-T
LAN2 RJ-45 Port: 1000BASE-T
2.4 GHz Radio IEEE 802.11b/g/n/ax
5 GHz Radio IEEE 802.11a/ac/n/ax
Bluetooth Radio IEEE 802.15.1
Radio Frequencies 2.4 – 2.4835 GHz (US, Canada, ETSI)
5.15 – 5.25 GHz (lower band) US/Canada,
Europe
5.725 – 5.825 GHz (upper band) US/Canada
Power Specifications
PoE Input Power 22.4 W max, 48 VDC–55 VDC;
802.3at-compliant
AC Power Adapter AC Input: 100–240 VAC, 50-60 Hz
DC Output: 12 VDC, 2 A
Regulatory Compliances
Radio EN300 328 V2.2.2 (2019-07)
EN301 893 V2.1.1(2017-03)
47 CFR FCC Part 15.247
47 CFR FCC Part 15.407
NCC LP002
MIC certification Rule, Article 2 Paragraph 1 Item
19
MIC certification Rule, Article 2 Paragraph 1 Item
19-3 and 19-3-2
Emissions EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 55032:2015
EN 55024:2010/A1:2015
AS/NZS CISPR 32:2015, Class B
47 CFR FCC Rules and Regulations Part 15
Subpart B, Class B Digital Device
CNS 13438
Safety Low Voltage Directive (2014/35/EU, formerly
2006/95/EC, formerly 73/23/EEC)
CNS 14336-1
IEC/EN 62368-1, IEC/EN 60950-1
Taiwan RoHS CNS 15663
