C
HAPTER
3
| Installing the Switch
Installing an Optional SFP Transceiver
– 42 –
3. If installing a single switch only, turn to “Connecting to a Power Source” on
page 45.
4. If installing multiple switches, mount them in the rack, one below the other,
in any order.
DESKTOP OR SHELF MOUNTING
The switch includes four pre-installed rubber feet for desktop or shelf mounting.
To mount devices on a horizontal surface, follow these steps:
1. Set the device on a flat surface near an AC power source, making sure there
are at least two inches of space on all sides for proper air flow.
2. If installing a single switch only, go to “Connecting to a Power Source” on
page 45.
3. If installing multiple switches, place each device squarely on top of the one
below, in any order.
INSTALLING AN OPTIONAL SFP TRANSCEIVER
The SFP slots support the following optional SFP transceivers:
◆ 1000BASE-SX
◆ 1000BASE-LX
◆ 1000BASE-LH
◆ 1000BASE-LHX
◆ 1000BASE-ZX
◆ 1000BASE-BX20
◆ 1000BASE-BX10
