Edge-Core ECW7220-L User Manual

Quick Start Guide
– 2 –
5. Manage the AP from the Controller
The AP is designed to be managed from an EWS4502 or
EWS4606 wireless controller. For information on AP
management, refer to the wireless controller Administrator’s
Guide and CLI Command Reference, which are on the Edge-
Core web site, www.edge-core.com.
1
Hardware Specifications
Chassis
Size (WxDxH) 200 x 200 x 36.5 mm (7.87 x 7.87 x 1.44 in)
Weight 750 g (1.65 lb)
Temperature Operating: 0° C to 40° C (32° F to 104° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 5% to 95% (non-condensing)
Network Interfaces
Ports Eth0/PoE Port: 1000BASE-T, PoE+ PD
Eth1 Port: 1000BASE-T
2.4 GHz Radio IEEE 802.11b/g/n
5 GHz Radio IEEE 802.11a/ac/n
Radio Frequencies 2412 - 2472 MHz (ETSI),
2412 - 2462 MHz (FCC)
5745 - 5825 MHz (China)
5180 - 5240 MHz (ETSI)
5180 - 5240 MHz, 5745 - 5825 MHz (FCC)
Power Supply
PoE Input Power 48 VDC, 0.6 A
Power Consumption 22.5 W maximum
Regulatory Compliances
Radio EN 300 328 V1.8.1:2012 (2012-06)
EN 301 893 V1.7.1:2012 (2012-06)
FCC Part 15C 15.247/15.207 (2.4-2.4835 GHz)
FCC Part 15E 15.407 (5.150GHz-5.250 GHz,
5.725-5.850 GHz)
Emissions EN 55022 2010/ AC: 2011, Class B
FCC Part 15 Subpart B, Class B
ICES-003, Issue 5, Class B
Immunity EN 55024 : 2010
EN 301 489-1 V1.9.2 (2011-09), Class B
EN 301 489-17 V2.2.1 (2012-09)
AS/NZS CISPR 22: 2009/Amdt 1: 2010, Class B
Safety UL (CSA 22.2 No. 60950-1 & UL60950-1)
CB (IEC/EN60950-1)

Edge-Core ECW7220-L Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Network Interfaces

eth0/poe port	1000BASE-T, PoE+ PD
eth1 port	1000BASE-T
2.4 ghz radio	IEEE 802.11b/g/n

Power

poe input power	48 VDC, 0.6 A
power consumption	22.5 W maximum

Weight and Dimensions

size	200 x 200 x 36.5 mm
weight	750 g
