EdgeStar CWB2886FD - Defrosting Process; Automatic Defrosting

- 14 -
3.
DISASSEMB
LY
4.
Pull out the LED light. The LED light is like below.
(figure 20)
Figure 20
(Models：CWR70SZ)
1.
Loosen one screw. (figure 21)
Figure 21
2.
P
ull out the electrical box
. (figure 22)
Figure 22
3. Rem
ove the electrical box cover
(figure 23)
Figure 23
4.Remove the LED light connector.
(figure 24)
Figure 24
5.Rem
ove the LED light fixer and take out the LED
light.
(figure 25)
Figure 25
6. The LED light is like below. (figure 2 6 )
Figure 26
( Models：RP400MED)
1、Remove four screws and take out the electrical box .
(figure 2 7 )
Figure 27
