EDIFIER T5 User Manual

6
English
Operational Guide
Connections:
Connection 1:
“Subwoofer Output” connection:
If audio source device has the port like “Sub Out”, “Woofer Out”, “SW Out” or “LFE Out”, namely the line output port
specialized for connecting subwoofer, please connect this output port to “Signal In” port on the subwoofer using
audio cable.
Connection 2:
“Left and Right Sound Channel Output” connection:
If audio source device has no dedicated subwoofer output port but has left and right sound channel line output
port (LINE OUT) (or FL/FR output port on the devices supporting 5.1/7.1 channels), please connect this left and right
sound channel line’s output port to “Signal In” port on the subwoofer using audio cable, then connect “Signal Out”
port on the subwoofer to audio input port on the powered main speaker.
Volume Adjustment:
To achieve optimum listening effect, ensure the subwoofer’s volume is reasonably matched with that of the main speaker.
Please set the subwoofer’s volume to the minimum level prior to adjustment.
If connected by connection 1:
1) Set Bass Adjustment of audio source device to the “middle” or “0 dB” position (if have).
2) Play audio source containing low frequency components and adjust the main speaker’s volume to an appropriate
level &
3) Gradually increase the subwoofer’s volume until it can be matched with that of the main speaker;
After adjustment is finished, adjusting the audio source device’s master volume can control the subwoofer and other
speaker’s volume simultaneously.

EDIFIER T5 Specifications

General

Subwoofer type	Active subwoofer
Low pass filter	Yes
Input sensitivity	50 mV
Subwoofer sensitivity	85 dB
Subwoofer frequency range	38 - 200 Hz
Subwoofer driver diameter (imperial)	8 \
Material	MDF
Product color	Black
AC input voltage	100 - 240 V

Weight and Dimensions

Subwoofer depth	300 mm
Subwoofer width	278 mm
Subwoofer height	336 mm
Subwoofer weight	13000 g
