EN Installation, use and maintenance page 2
EVIA
PELLET STOVE

Questions and Answers

  • N
    nsantosJul 27, 2025
    What to do if my EdilKamin Pellet stove displays H04 error?
    • D
      davidcortezJul 27, 2025
      If your EdilKamin pellet stove displays the H04 error, which indicates unsuccessful ignition, here's what you can do: * If there is no flame, ensure the burning pot is properly seated and clean. Also, check that there are pellets in the tank and burning pot. You can try using a piece of solid paraffin to light the stove, but contact a technician first. * If a flame is present, it is advisable to contact a technician for further assistance.
  • J
    Jerry WilsonAug 1, 2025
    Why does my EdilKamin EVIA display H01 error?
    • K
      Kaitlin ParksAug 1, 2025
      The H01 error on your EdilKamin pellet stove indicates that the combustion air intake is below the set level. To resolve this, check that the combustion chamber door is closed and ensure that the stove, exhaust, and combustion air ducts are clean.
  • T
    Travis MarshallAug 7, 2025
    What to do if my EdilKamin EVIA Pellet stove displays HO7 error?
    • D
      Dwayne AbbottAug 7, 2025
      If your EdilKamin pellet stove displays the HO7 error, which means that the maximum fumes temperature has been exceeded, check the type of pellet you are using. If you are unsure about the correct type of pellet, contact a technician.
  • J
    Joshua MooreAug 11, 2025
    What to do if my EdilKamin Pellet stove is overheating (H08 error)?
    • B
      Bobby GrayAug 11, 2025
      If your EdilKamin pellet stove is switching off due to excessive overheating (error H08), refer to the solutions for error HO7. Check the type of pellet.
  • J
    John WatsonAug 16, 2025
    What does H11 error mean on my EdilKamin EVIA and how to fix it?
    • L
      Luis YoderAug 16, 2025
      The H11 error on your EdilKamin pellet stove indicates that it has switched off due to the activation of the safety pressure switch. Make sure that the stove and flue are clean.
  • J
    John DavisAug 21, 2025
    What does H03 error mean on EdilKamin EVIA Pellet stove?
    • D
      David EricksonAug 21, 2025
      The H03 error on your EdilKamin pellet stove means that the thermocouple is detecting a fume temperature lower than the set value, which the stove interprets as the absence of flame. Check that there are pellets in the tank.

Summary

Product and Warranty Information

First Ignition and Commissioning

Explains the process and importance of first ignition by an authorized technician.

Safety Information

Safety Risks and Precautions

Highlights potential safety risks from installation, contact with parts, electrical hazards, improper fuel, and cleaning.

Unpacking Procedures

Removing Stove from Pallet

Step-by-step instructions for safely removing the stove from its pallet.

Installation

Installation Remarks

Notes on required personnel, compliance with regulations, and condominium installation approval.

Installation Space Suitability

Criteria for selecting a suitable installation space, including volume, floor load, and room restrictions.

Heat Protection and Safety Clearances

Specifies minimum clearances from flammable materials and heat protection requirements.

Installation Details

Flue System Requirements

Details requirements for fumes duct, flue, and chimney pot according to European standards.

Fumes Duct and Flue Specifications

Lists requirements for fumes duct and flue, including material, routing, bends, and cleaning access.

Fumes Duct Details

Specific rules for fumes duct material, insulation, routing through rooms, and inspection.

Installation Specifics

Flue Specifications

Further requirements for the flue, including material, dimensions, insulation, and condensation collection.

External Air Intake

Details on indirect and direct air intake methods, including surface area and routing.

Installation Electricals

Electrical Connection Checks

Guidance on connecting the stove to the power supply, socket accessibility, and voltage variations.

User Instructions

First Ignition Phases

Steps for first ignition, including reading the manual and technician's role.

Fuel Specifications

Defines the type of wood pellets to use and prohibits burning other materials.

Loading Pellets into the Tank

User Operation

Operation Modes

User Interface and Control

Remote Control Usage

Remote Control Details

Remote Control Buttons

User Controls and Functions

Ventilation Setting

On;Off Control

Switch-on;Switch-off Operation

Manual;Automatic Mode Setting

Advanced User Functions

Relax Function

Standby Function

Menu Navigation

Crono Functionality

Crono Function Setup

Guide to enabling Crono mode, setting daily schedules and temperature setpoints.

Crono Settings Configuration

Crono Temperature and Time Settings

Instructions for setting three distinct temperature setpoints and time periods within the Crono function.

Crono Settings Management

Crono Settings Management

Procedure for changing, viewing, or resetting Crono time settings and saving configurations.

Maintenance Procedures

Maintenance Notes and Warranty

Daily Maintenance Procedures

Maintenance Schedule

Weekly Maintenance

Troubleshooting Guide

Shutdown Messages and Solutions

Lists common shutdown messages (H01-H06) and their corresponding problems and solutions.

EdilKamin EVIA Specifications

General IconGeneral
TypePellet stove
Fuel typePellets
Flue outlet diameter80 mm
ControlDigital panel
Power supply230V / 50Hz
Hopper capacity15 kg
Heating volume230 m³
