TECHNICAL CHARACTERISTICS according to EN 13229 The given data are indicative and taken
during the certification stage at a notified Body under regulation conditions.
The results were obtained with the glass cleaning system closed, by the installer.
WINDO 70 WINDO 90 WINDO 100 WINDO 120
Nominal power
Power output 14,3 17,6 18 19,2 kW
Efficiency 81,4 81,1 78,2 78,2 %
Emissions CO 13% O
2
0,07 0,09 0,07 0,06 %
Fumes temperature 252 238 261 216 °C
Minimum draught 11 12 11 11 Pa
Fuel consumption * 3,8 4,7 5 5,3 kg/h
Heatable volume ** 375 460 470 500 m
3
Smoke outlet pipe diameter 180 mm
Weight including packaging 220 250 380 430 kg
Energy efficiency class accor-
ding to UE 2015- 1186 regula-
tion (Class A++/G)
A+ A+ A A
TECHNICAL DATA FOR THE DIMENSIONING OF THE FLUE
WINDO 70 WINDO 90 WINDO 100 WINDO 120
Nominal power
Temperature of fumes on exit from
the discharge pipe
302 285 313 313 °C
Minimum draught 10 10 10 10 Pa
Fume flow capacity 12 13 17,7 18,9 g/s
GENERAL INFORMATION
Intermittent mode combustion device
*A calorific value of 4.8 kW/Kg has been used to calculate consumption
** The heating volume is calculated with the heat request of 33 Kcal/m³ hour
EDILKAMIN s.p.a. reserves the right to change the products at its discretion without notice.
