2 / 2 P/N 3100156 • REV 002 • ISS 31JAN17
Glass rod
Mounting brackets
Front cover
(rear view)
Figure 2: Glass rod installation
Figure 3: Toggle switch in normal position
Figure 4: Mounted releasing station
Wiring diagram
See the appropriate module or panel installation sheet for wiring specifications
Second circuit may be connected or left open
To next device or end -of-line resistor
Release Station (rear view)
From releasing panel, module, or device
Figure 5: Wiring terminals as seen from rear view
