R-Series Remote Annunciators and Expanders Installation and Operation Guide 9
Figure 8: Typical annunciator wiring
(1) CH1_IN+/− from the control panel or previous annunciator. CH1_OUT+/− to the next
annunciator or to the control panel if the last annunciator on a Class A circuit.
(2) CH2_IN+/− from the control panel or previous annunciator. CH2_OUT+/− to the next
annunciator. Used only on redundant Class B circuits. See Figure 6 on page 8.
(3) Use the control panel power supply or a 24 VDC, continuous, regulated, power supply that is
UL/ULC Listed for fire protective signaling systems.
(4) To the expander. See Figure 9.
(5) The remote key switch wiring is not supervised. The key switch must be located within 3 ft.
(0.9 m) of the annunciator and installed in conduit, or equivalent protection against
mechanical injury.
A remote key switch is required on RLED-C remote annunciators.
Figure 9: Typical expander wiring
RLCD(-C) / RLED(-C)
Ch1( )_IN
Ch1( )_IN
Ch1( )_OUT
Ch1( )_OUT
24V( )_IN
24V( )_IN
24V( )_OUT
24V( )_OUT
RKE
Y
LOCK(+)
LOCK(- )
EGND
Ch2( )_IN
Ch2( )_IN
Ch2( )_OUT
Ch2( )_OUT
V( )_OUT
V( )_OUT
F_OUT
E_OUT
D_OUT
C_OUT
B_OUT
A_OUT
(1)
(2)
(3)
(4)
(5)
V( )_IN
V( )_OUT
V( )_IN
V( )_OUT
F_IN
F_OUT
RLED24
E
_
IN
E_OUT
D_IN
D_OUT
C_IN
C_OUT
B_IN
B_OUT
A_IN
A_OUT
V( )_INV( )_OUT
V( )_IN
V( )_OUT
F_IN
F_OUT
E_IN
E_OUT
D_IN
D_OUT
C_IN
C_OUT
B_IN
B_OUT
A_IN
A_OUT
RLED24
RLCD(-C) /
RLED(-C)
