2 R-Series Remote Annunciators and Expanders Installation and Operation Guide
The annunciators communicate with the FACP on the RS-485 data riser. This
can be configured for Class A or Class B communication. The annunciators do
not provide ground fault isolation.
The annunciators are stand-alone units that can be powered by the FACP or by
an approved power supply.
Models with common controls can use a separate, remote key switch to enable
or disable the common controls.
Table 2: R-Series models and accessories
Model number Description
RLCD Remote Annunciator: LCD text annunciator without common controls.
English.
RLCD-R Remote Annunciator: LCD text annunciator without common controls.
English. Red.
RLCDF Remote Annunciator: LCD text annunciator without common controls.
French.
RLCD-C Remote Annunciator: LCD text annunciator with common controls.
English.
RLCD-CR Remote Annunciator: LCD text annunciator with common controls.
English. Red.
RLCD-CF Remote Annunciator: LCD text annunciator with common controls.
French.
RLED-C Remote Annunciator: 16-pair LED zone annunciator with common
controls. English.
RLED-CR Remote Annunciator: 16-pair LED zone annunciator with common
controls. English. Red.
RLED-CF Remote Annunciator: 16-pair LED zone annunciator with common
controls. French.
RLED24 Remote Expander: 24-pair LED zone expander with expander cable and
zone card insert.
RLED24R Remote Expander: 24-pair LED zone expander with expander cable and
zone card insert. Red.
RA-ENC1 One-position enclosure for Remote Annunciator.
RA-ENC2 Two-position enclosure for Remote Annunciator and one Remote
Expander, including one interconnection cable.
RA-ENC3 Three-position enclosure for Remote Annunciator and two Remote
Expanders, including two interconnection cables.
RKEY Remote key switch on plate for enabling or disabling common controls
(Lock/Unlock).
RA-LED16ZC Zone card insert for RLED-C, RLED-CR, and RLED-CF.
RA-LED24ZC Zone card insert for RLED24, RLED24R.
