Plumbing Installation Visual Guidance – Layout A
A.
F.
Existing Household Plumbing
.875”/ ¾ Copper Tube
Push-to-Connect Fitting
½“ Nut
½” Ferrule
½“ Nut
½” Ferrule
¾” Female NPT to ⅝” Tube Adapter
Existing ¾” Male NPT From Tank
(OUTLET SIDE OF TANK)
D.
B.
E.
C.
Step 2
Step 1
