4. Installation
27
1. unit
2. connecting line to fuel cell
3. extension sense line (optional)
4. battery fuse 2 A
5. battery
6. extension power line with 2- or 3- pole plug (optional)
7. Central electrical box (EBL)
or
Fuse 2A
4
1
2
3
5
6
r
ed
b
r
o
wn
7
