GRASS BAGGER — ABK42004
Counter weight
Left Right
2
Post
2
Crossbar
1
Mounting bracket
Left Right
2
Lock pin
2
Retention pin
2
Hexagon head bolt and nut set
M8*70
4
Step bolt and nut set
M8*90
4
