2 © 2013 - 2017, Euro Games Technology Ltd.
HARDWARE
Rev.1.0. - an initial document version
Rev.1.1. - a new document version with following changes:
A new point II.2. TOP LAMP MOUNTING is added to CHAPTER ІІ. INSTALLATION on
pages 13-14.
A new functionality of Cash Out and Select Game buttons is described on page 50;
Rev.1.2. - a new document version with following changes:
The machine keyboard is changed on page 49 and description of buttons functionality when
Roulette and Keno Universe are played.
A picture and description of OLED keyboard is added on page 53.
Rev.1.3. - a new document version with following changes:
The height of the gaming machine is corrected on page 9.
Rev.1.4. - a new document version with following changes:
New optional models of bill validators are added on pages 30-31.
Rev.1.5. - a new document version with following changes:
The picture of the distributor box is replaced with correct one on fig IV.2 on page 26;
New optional model bill validator - JCM iVizion-SS is added and described on pages 32,
34 and 43.
Rev. 1.6. - a new version of the document with following changes:
An additional warning, regarding the mechanism for opening the main door as well as a
safety measure on p. 11.
-A new subsection III. 7. Main Door Opening and Closing is added - p. 22.
Rev. 1.7. - a new version of the document with the following changes:
Added information about specialized gaming platform Exciter III - p. 7, 29, 32;
Added information about Connectors of Exciter III Connectors Board - p. 78.
Rev. 1.8. - a new version of the document with the following changes:
Updated Modular Diagram of Components - p. 71.
Rev. 2.0. - a new version of the document with the following changes:
Updated Chapter III.4. Jackpot Payout - p. 25-27.
A new optional model of Ticket printer - JIM Global GEN5 - p. 56, 58.
A new Modular Diagram of Components - p. 79.
A new Electric Wiring Diagram - p. 80-81.
REVISION HISTORY
REVISION HISTORY
