1 2 3
4 5 6
10
Permanent Drain Option
A hose with an inner diameter of 12mm can be connected for
continuous drainage.
1. Remove the tank
2. Using a screwdriver, remove the ‘knock-out’ located on the back of
the appliance and pass the hose through the hole.
3. Attach the hose firmly to the ‘L’ shaped drain connector.
4. Connect the ‘L’ shaped drain connector to the drain outlet.
5. Rotate clockwise to fix the connector into position.
6. Restore the water tank in the correct position.
