Welcome to the Electro-Harmonix Deep Freeze Sound
Retainer. With the simple push of a button, the Deep Freeze
allows you to sustain individual notes and chords indefinitely,
gliss between frozen sounds, layer sounds and notes, and
automatically freeze notes or chords as you play. All of this
in an extremely compact, pedalboard-friendly package!
Operating Instructions
Insert the output plug from the supplied 9VDC AC adapter
into the power jack at the top of the Deep Freeze. The unit
must be powered to pass signal, even in bypass. The Deep
Freeze features buffered analog bypass or digital bypass
depending on settings. Connect an instrument cable from
your instrument to the Input jack. Connect an instrument
cable between the Output jack and a suitable amplifier.
As a starting point, set the DRY and EFFECT knobs to 50%
and the SPEED/LAYER and GLISS knobs to minimum.
Controls & Jacks
1. MODE Button Selects how the footswitch controls the effect.
LATCH (Green LED) Play a note or chord and then press
and release the footswitch to activate the effect and light
the LED green. After you release the footswitch, the effect
remains active and your sound sustains indefinitely. Dou-
8
9
2 3
1
6
6
4 5
7
DRYEFFECT
MODE
GLISS
SPEED
LAYER
Power Suppy Requirements: Voltage: 9VDC Current: 100mA Polarity: Center-Negative
This device comes equipped with an Electro-Harmonix 9.6DC-200 power supply. Use of the wrong adapter or a
plug with the wrong polarity may damage the device and void the warranty. Do not exceed 10.5VDC on the power
plug. Power supplies rated for less than 100mA may cause the device to act unreliably.
