Figure 2. Location in rooms with sloped ceilings
- 300mm from apex of ceiling
- High side of the room
CO Alarm
about
1 to 2m
Figure 3. Location in bedroom & rooms remote
from the appliance
- Wall mounted
- Breathing level (approx. 1 to 2m above floor)
8
300mm
150mm
1 to 3 m
1 to 3 m
DEAD AIR
DON'T LOCATE
HERE
CO Alarm
Figure 1. Location in room with a fuel burning
appliance
- 1 to 3m from appliance
- Ceiling 300mm (min) from wall - Wall 150mm
vertically down from ceiling
