Eilon Engineering Ltd. RON 2501 NG Operating Manual 18
A “PRINT” line includes the following:
1. The value (5 digits)
2. The units
3. TARE mode “NET” or “GROSS”
4. Function: DATA = displayed data
MAX = PEAK HOLD = max. value
TOT. 21 = Totalized value and number of loads
summed-up, 21 in this case
D.L. 1 = Data Logger line #1
D.L. 2 = Data Logger line #2
5. DATE & TIME – if the system is equipped with a “real time clock”
option.
8.6 BAUD RATE SELECTION
If applicable, i.e. only if the system is equipped with the RS-232 output and
user-selectable baud rate options.
To enter the programming procedure menu options, follow the instructions in
chapter #7.
Select the BAUD. R = BAUD RATE procedure menu using the up and/or
down arrows.
Press: ENTER
Display: Blinks O.K. and then displays the baud rate that is currently in use.
Use the up and/or down arrows to select the desired rate. The
available baud rates, are: 38,400, 19,200, 9600, 4800, 2400, 1200
bps.
Press: ENTER. The display will blink the chosen baud rate and then the display
will blink O.K. and BAUD. R.
To quit the main menu press ESC.
To enter another menu procedure use the up an/or down arrows.
8.7 TOTALIZER – ONLY IF APPLICABLE
The totalizer sums-up loads. To sum-up an additional load press TOTAL. After
“TOTAL” is displayed press ENTER. The display will show “ADD” and then
N 17 will follow, meaning load #17 has been added and the current TOTAL in
the memory (25840 for example) will follow for a short time. The display
