Mains-powered variant
4
Remove the cover
1
Activate the eqiva BLUETOOTH® Smart Lock
Follow the instructions in the operating instructions for the
eqiva BLUETOOTH® Smart Lock
2
Cable through mounting plate
3
Attach the mounting plate (mount the ekey uno in the direct
vicinity of your door lock – height 110 cm)
*NOTICE: Remove the entire base foil. Thoroughly clean the surface where the device
is to be mounted. Adhere the mounting plate only to a smooth, dry surface at room
temperature. Apply a large amount of pressure to the surface to adhere the
mounting plate. The bond only reaches maximum adhesive strength after 3 days.
Only then can the mounting plate be fully loaded.
For further information, visit: www.ekey-uno.net/faq.
Glue variant*
An adhesive foil is already
attached to the mounting
plate. Remove the base foil
and adhere the mounting
plate.
OR
Screw variant
