Elan HC4 Quick Install Guide

PPRM2 PPRM3
IR IN
VIANET
IR3
GND
VSNS
SNS3
PPRM1
IR2
-
GND
-
VIA-
VIA+
-
SNS3
IR1
GND
VSNS
SNS1
GND
NC1
COM1
NO1
GND
VIR
GRD
VIR
-
-
-
EXT IR IN
IR2
GND
VSNS
SNS2
GND
NC2
COM2
NO2
VIANET
-
SNS1 EXT IR INSNS2
IR3
R2
IR1
R1
NO
COM
GND
-
-
-
GND
COM
NC
NO NC
DC Power Connection
VIA!Net Connection
Connect to the PPCM to provide Via!Net
information to TS2s connected to the PPVN.
Uses the ELAN standard color code.
Sense Input Connections
Connect to Sense Input
connections on the PPCM.
EXTERNAL IR Input
OSD Output &
Passthrough for
component video from
A/V Controller to a
monitor.
Serial Connections
4 RS232 and 1 RS485 ports.
Connect to PPIS panels or to serial controlled
devices using the supplied DB9-RJ45 adapters.
Relay Connections
Note: Only Room 1-2
punchdowns on the
PPCM have relay
connections.
IR Outputs
Connect to IR Output
connections on the PPCM
and / or to IR controlled
devices located in the rack.
Audio Output
Connect to Source Input
of the A/V Controller.
Provides audio out for the
Internal Player.
Ethernet Connection
USB Modem
Connection
Activity
Indicator
LEDS
PPCM
HC4
+12VDC
Power Supply
PPVN
PPIS
+16VDC
Power Supply
EXT IR IN
RJ-45
PPIR
RJ-45
RELAY
IR OUT
SENSE
PPRM
RJ-45 to
RS-232
Adapter
