ELCOM 7205 - Battery Charge Monitoring and Replacement; Programming the Electronic Lock; Programming the Master Combination; Troubleshooting Malfunctions

6. Monitoring the battery charge level, replacing the batteries
If the charge remaining in the batteries is insufficient, then the red and green LEDs will blink alternately 10 times after
the combination has been entered. This is to remind you to install two new 1.5 Volt AA (alkaline) cells in the next few
days.
Note: If you ignore the low-battery warning over a longer period of time, then you must be aware of the hazard that it will
be possible to open the lock and, as a consequence, the safe only after new batteries have been installed.
The battery compartment cover is located to the right of the keypad housing. Remove the Phillips screw and then slide
the battery compartment cover carefully off of the keypad housing in the direction indicated by the arrow. See Figure 1.
Remove the exhausted batteries and replace them with two new 1.5 volt AA (alkaline) batteries. The direction in which
the batteries are to be installed is shown inside the battery compartment cover. The programmed combination will be
retained during battery replacement.
7. Programming the electronic lock
Before you use your safe for the first time it is necessary, for security reasons, to enter your personal combination; the
factory combination must not be retained. The lock should be programmed only with the door open and with the
electronic lock released. Select your new six-digit combination before starting the easy programming sequence. Do not
use any personal data for this combination, such as birthdays or other information which could be derived from
knowledge about your person. Store your combination in a safe place so that only you have access to it.
7.1 Programming the master combination
Note: Program only with the door open and the electronic lock released. The green LED must not be lit.
Note:
We can assume no guarantee liability for malfunctions caused by erroneous reprogramming or application of undue
force or improper treatment nor in case of injury to property or assets which, for example, is due to a failure to close the
safe properly.
We recommend obtaining suitable insurance coverage to protect the contents of your safe. Your property insurance
sales agent can provide details.
8. Troubleshooting in case of malfunction
If it is not possible to open your safe in spite of having carried out the instructions above, then please contact the safe
manufacturer.
Function
Activate programming mode
Select programming mode
Confirm entry
Enter the previous six-digit
combination
Confirm entry
Enter the new six-digit combination
Confirm the entry
Verify the new combination by
repeating your entry
Confirm entry
Cancel
Operation,Button(s)
*
0
*
1 2 3 4 5 6
*
6 5 4 3 2 1
*
6 5 4 3 2 1
*
C
Response
OK = Green LED blinks twice
Invalid = Red LED lights for 3
seconds
Comments
Set for 1 - 2 - 3 - 4 - 5 - 6
at the factory
Important: Please check
to see that the lock
functions correctly with
the new master
combination before you
close the door to the
container
Problem
Red LED lights for about 3 seconds
after the combination is entered.
Electronic lock does not respond to
any keypad entries.
The red and green LEDs blink
alternately, ten times.
Possible cause
Invalid combination was entered.
The lock-out period was activated by
entering an invalid combination
several times in sequence.
Low battery charge
Red LED lights for about 3 seconds
after programming a new master
combination.
The new master combination was
improperly programmed. The old
combination is retained.
Remedy
Enter valid combination.
Repeat the programming of the new
combination as described in Item 7.1 of
the operating instructions.
See Item 4 in the operating instructions.
Change out the batteries. See Item 6 in
the operating instructions.
