ELECAENTA Mars EM200 - Output Port Details

OUTPUTS
① PD 60W USB C: 20V/3A, 15V/3A, 12V/3A, 9V/3A, 5V/3A
② QC 3.0 Output: 9~12V/3A, 6~9V/2A, 3.6~6V/3A, 5V/3A
③ QC 3.0 Output: 9~12V/3A, 6~9V/2A, 3.6~6V/3A, 5V/3A
④ QC 3.0 Output: 9~12V/3A, 6~9V/2A, 3.6~6V/3A, 5V/3A
⑤ DC Output (5.5×2.1mm): 12V/5A (Max 6A)
⑥ DC Output (5.5×2.1mm): 12V/5A (Max 6A)
⑦ DC Output (5.5×2.1mm): 12V/5A (Max 6A)
⑧ AC Output (Pure Sine Wave): 200W (Peak 400W)
⑨ AC Output (Pure Sine Wave): 200W (Peak 400W)
Note:
1. When using outputs ① ② at the same time, the max output is 30W.
2. When using outputs ③ ④ at the same time, the max output is 30W.
3. When using outputs ① ② ③ ④ at the same time, the maximum output power is 60W.
4. When using outputs ① ③ ④ at the same time, the maximum output power is 90W.
5. When using outputs ⑤ ⑥ ⑦ at the same time, the max output is 60W.
6. When using outputs ⑧ ⑨ at the same time, the max output is 200W.
①
②
③
⑥
⑦
⑤
④
EN-07
⑧
⑨
⑧
US UK
