18
connections, refer to the “Assembly of gas supply and leakage
check” clause explained before.
Anti-Tilting Kit
Anti-Tilting Bracket (x1)
(Will be installed to the
wall)
Adaptor (x1)
(Installed on the product)
The document bag contains an anti-tilting kit. Anti-tilting bracket
(1) should be removed from the kit and installed onto the wall
with the following measures. The adaptor (2) that will provide
connection of the anti-tilting bracket to the oven is preinstalled to
the oven with 4 screws. The height can be adjusted by loosening
the 4 screws of the adaptor. After installation of the anti-tinting
bracket to the wall, push the product up to wall and check if the
bracket is placed on the cut out on the adaptor.
