Anti-Tilting Bracket Ground
Mounting Information
PRODUCT THE MODEL A B
60x60
50x60
85 cm product 57 53,7
90 cm product 53 48,2
50x50
85 cm product 57 39,4
90 cm product 53 33,9
The anti-tilting bracket is screwed on the
ground in the shown dimensions. The
product is xed to the anti-tilting bracket
by its adjustable foot.
