Warning! Do not attempt to lift any of the scooter components unless you are capable of doing so. The
weight for each component is shown in the Technical Specification (page 27)
Warning! Do not attempt to lift the chassis un-assisted - back or other injury may result!
To remove the seat:
1
. Fold the seat-back flat and grasp the seat as shown (Fig 14) and lift it away from the scooter frame.
Tip: Removing the seat may be easier if you first use the seat swivel function to rotate the seat so it is at
90˚ to the scooter before lifting.
T
o fold the tiller:
1. Having first removed the seat, loosen the tiller thumb-wheel (Fig 15) and then re-tighten when the
tiller is parallel to the chassis.
Tip: Alternatively the seat and tiller can be folded towards each other to reduce overall height and facilitate
easier storage of the scooter (Fig 16)
