The center position (marked 0) applies zero
attenuation before the mic’s preamp.
The left-hand position (marked -10) applies
10dB of attenuation before the mic’s built-in
preamp.
The right-hand position (market -20) applies
20dB of attenuation before the mic’s built-in
preamp.
-20
-10
0
Pad
0, -10dB,
-20dB
Using the hi-pass filters
The ND66 contains a 3-position sliding switch whose
selected position will engage high-pass filter settings.
Adjusting the filter setting requires a small flat head
screwdriver (or some other means of sliding the
switch) using the switch’s slot as a leverage point.
With the slot in the sliding switch in the
center position (as shown), the filter is flat
and there is no roll-off applied.
Slot
Sliding the slot upwards revealing 75 (as
shown) engages a 12 dB per octave roll-off
at 75 Hz.
75
High
Pass
75 Hz
Sliding the slot downwards revealing 150 (as
shown) engages a 12 dB per octave roll-off
at 150 Hz.
150
High
Pass
150 Hz
Parts included
Qty. Item
1 Microphone
1 WSND-1 foam windscreen
1 Gig bag
1 Stand clip
1 Euro thread adapter
1 Engineering data sheet
1 Warranty and Product Documentation Information card
Ordering information
ND66
Condenser cardioid instrument microphone, black
Order number ND66
SAND-1
Stand adapter, black
Order number SAND-1
WSND-1
Replacement foam windscreen for ND66, black
Order number WSND-1
ND66RING
Replacement transition ring between head and body,
silver
Order number ND66RING
Accessories
DRC-2
Drum rim clamp, black
Order number DRC-2
