41
Cleaning the aluminum bar area:
If you really
need to remove
the aluminum
bar to clean
up the door
area where the
bar is fitted,
proceed as
follows: Press
the buttons of the aluminum bar locks (1) and
turn in the opposite direction of the door (2).
The buttons can be pressed one at a time. After
that, push the aluminum bar in the direction as
shown in the drawing.
Fruit tray
Tilt the frontal part
of the tray (1). From
inside, hold with your
hand, push up (2) and
pulling forward (3)
simultaneously.
Extra cold drawer
To remove the extra cold
drawer, just pull it as shown,
and then up.
Refrigerator bottom
shelf
Just pull up.
Vegetables and
fruits drawer
Remove the fruit tray as
procedure above. Pull
the drawer (1) forward
until the drawer stops.
Tilt the drawer up until
the stopper out of the
housing (2). Pull the
drawer (3).
