Electrolux ECVW3062AS - Electrical Connections; Electrical Connections and Wiring

Insert the upper chimney (Item 2.1) into
the lower chimney (Item 2.2) from top to
bottom (fig. ).
Mount lower chimney (Item 2.2) on the
range hood (Item 1).
Fit the lower chimney (Item 2.2) to the
lower bracket (Item 5) using 2 screws
(Item 14) by hand (fig. )then tighten the
screws using screw driver(fig. )
CAUTION
