Electrolux EGD6576NOK User Manual

R 5mm
min.
55mm
490
+1
mm
560
+1
mm
600 mm
min.
38 mm
min.
2 mm
min.
12 mm
min.
2 mm
CAUTION!
Install the appliance only on
a worktop with a flat surface.
3.11 Possibilities for insertion
Kitchen unit with door
The panel installed below the hob must
be easy to remove and let an easy
access in case a technical assistance
intervention is necessary.
min 20 mm
(max 150 mm)
60 mm
B
A
A. Removable panel
B. Space for connections
Kitchen unit with oven
The electrical connection of the hob and
the oven must be installed separately for
safety reasons and to let easy remove
oven from the unit.
www.electrolux.com12

Electrolux EGD6576NOK Specifications

General

Hob type	Combi
Frame type	Frameless
Product color	Black
Hob width size	60 cm
Top surface type	-
Appliance placement	Built-in
Cooking zone 1 type	Simmer
Cooking zone 2 type	Large
Cooking zone 4 type	Regular
Cooking zone 1 boost	2500 W
Cooking zone 1 power	1900 W
Cooking zone 1 shape	Round
Cooking zone 2 boost	3300 W
Cooking zone 2 power	2300 W
Cooking zone 3 power	2700 W
Cooking zone 4 power	1400 W
Pan support material	Cast iron
Cooking zone 1 diameter	70 mm
Cooking zone 1 position	Right front
Cooking zone 2 diameter	210 mm
Cooking zone 2 position	Left front
Cooking zone 3 diameter	100 mm
Cooking zone 3 position	Right rear
Cooking zone 4 diameter	140 mm
Cooking zone 4 position	Left rear
Number of cooking zones	4 zone(s)
Cooking zone 1 power source	Electric
Cooking zone 3 power source	Gas
Number of gas cooking zones	2 zone(s)
Timer	Yes
Control type	Touch, Rotary
Control position	Top front
AC input voltage	230 V
AC input frequency	50 Hz
Connected load (gas)	4800 W
Connected load (electric)	3700 W
Package depth	630 mm
Package width	720 mm
Package height	160 mm
Package weight	12100 g

Weight and Dimensions

Depth	520 mm
Width	590 mm
Height	50 mm
Weight	11500 g
Cord length	1.1 m
Installation compartment depth	490 mm
Installation compartment width	560 mm
