Remove the correct part from the hinge
cover (E). Make sure to remove the part
DX, in the case of right hinge, SX in oppo-
site case.
E
E
D
C
Attach the covers (C, D) to the lugs and the
hinge holes.
Attach the hinge covers (E) to the hinge.
Disconnect the parts (Ha), (Hb), (Hc) and
(Hd).
ENGLISH 17
