- 28 -
Spares Operation 08.01 A. B. 599 51 19 69 EN
Routine 2 see basic setting 1 5
1
in red
2
white
routine number
relay number
By pressing the minute minder key you can switch on resp. off the particular relays of the relay unit in this
programme. By pressing the key COOKING DURATION and COOKING END simultaneously you can
select the corresponding relay, max. 10, less depending on covering.
ATTENTION! The switching-on time should be short, as neither cooling fan nor hot air ventilator are
running and too long switching-on times could lead to damages.
1 M2 fan K61 approx. 100 mA
2 partial function steam K62
3 R 19 drawer heating K63 approx. 1.5 A
4 R3 grill heating element K64 approx. 4.5 A
5 M1 hot air K65 approx.100 mA
6 R4 ring heating element K66 approx. 6 A
7 no function K67
8 partial function steam K68
9 R2 lower heat K69 approx. 2.8 A
10 R 1 upper heat K70 approx. 3 A
There is no reliable declaration for the partial function steam (K62 + K68), of what is measured. These
both relays had to react together. The oven ligthing is controlled via the main contactor. E4 and S1
Routine 3 see basic setting 1 5
food thermometer
white
30
1
white
routine number
2
white
33
oven sensor
red
Routine 3 shows the temperature of oven sensor and food thermometer (if it is plugged in).
Note: Both temperatures normally differ, because there are different measuring points.
