1. Open the door with the appliance in the
upright position. Unscrew the screws
(t1) and remove the upper door plastic
trim (t2). Close the door.
t1
d7
t1
t1
t2
t3
2. Remove the little plastic cover from the
door plastic trim and refit on the oppo-
site side (t3).
3. Remove the panel (t4). If it is necessary
use a screwdriver very carefully. Un-
screw the screw on the other side. Re-
move the upper door mount (t5). Place
them in an empty plastic bag.
t5
t4
4. Remove the door.
5. Unscrew the screw and remove the
door stopper (d1). Attach it reversed on
the other side.
d1
6. Remove using a tool the cover (b1).
Unscrew the lower hinge pivot (b2) and
the spacer (b3) and place them on the
opposite side.
7. Re-insert the cover (b1) on the opposite
side.
b1
b2
b3
8. Re-insert the door on the pivot pin (b2).
Make sure that the edges of the doors
run parallel to the side edge of the ap-
pliance.
electrolux 25
