• Remove the lower door.
• Loosen the lower pin.
On the opposite side:
• Install the lower pin.
• Install the lower door.
• Refit the pins (B) and the spacers (C) on
the middle hinge on the opposite side.
• Install the upper door.
• Tighten the spacer and the upper pin.
VENTILATION REQUIREMENTS
5 cm
min.
200 cm
2
min.
200 cm
2
The airflow behind the appliance must be
sufficient.
INSTALLING THE APPLIANCE
CAUTION!
Make sure that the mains cable
can move freely.
Do these steps.
x
x
If necessary cut the adhesive sealing strip
and then apply it to the appliance as shown
in figure.
ENGLISH 41
