Electrolux ERN3213AOW - Hinge Covers and Part Disconnection

Remove the correct part from the hinge
cover (E). Make sure to remove the part
DX, in the case of right hinge, SX in oppo-
site case.
E
E
B
D
C
Attach the covers (C, D) to the lugs and
the hinge holes.
Install the vent grille (B).
Attach the hinge covers (E) to the hinge.
Disconnect the parts (Ha), (Hb), (Hc) and
(Hd).
